Blackmagic UltraStudio Recorder 3G (HDMI / USB Capture Card)
Blackmagic UltraStudio Recorder 3G (HDMI / USB Capture Card)
Description:
Video Capture Device
Records uncompressed and compressed video in highest 10-bit quality and is compatible with all common video software, e.g. DaVinci Resolve, Avid Media Composer, Adobe Premiere Pro CC and many more
SDI video inputs: 1x SDI rates 270 Mbit, 1.5G, 3G
SDI audio inputs: 16x channels embedded in SD/HD
HDMI video inputs: 1x
HDMI audio inputs: 8x channels embedded in SD/HD
Computer interface: Thunderbolt 3 (Mac OS, Windows and Linux)
Supported codecs: AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, uncompressed 8 bit 4: 2:2, uncompressed 10 bit 4:2:2, uncompressed 10 bit 4:4:4
Included software: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic drivers for Mac OS and Windows Media Express, Blackmagic Desktop Video Utility and Blackmagic drivers for Linux
Supported software applications: DaVinci Resolve, Adobe Premiere Pro CC, Adobe Photoshop CC, Sony Catalyst Production Suite, Grass Valley Edius, Tools On Air Just In, Softron MovieRecorder and Mreplay, Adobe Flash Media Live Encoder, Metus Ingest, Cinegy Capture Pro, Glookast Capturer, Burst Video [REC]Marker and Webclip2Go, Telestream Wirecast, Resolume Arena, Vegas Creative Software Vegas Pro, VidblasterX Studio and Broadcast, Unimedia Technologies UniplayOne and Uniplay-CG, CasparCG Server, Magicsoft CG, Xsplit Broadcaster, DevTek Easy Media Suite, Boinx Software MimoLive, StudioCoast vMix, Renewed Vision ProPresenter, Ventuz Director, Class X Liveboard and CoralCG, Open Broadcaster Software Studio, Nautilus Studio Nemo3D, Derivative TouchDesigner, Assimilate Scratch and Live Assist, NewBlue Title Live and Titler Pro, SGO Mistika
SDI SD video standards: 525i/59.94 NTSC, 625i/50 PAL
SDI HD video standards: 20p/50; 720p/59.94; 720p/60; 1080p/23.98; 1080p/24; 1080p/25; 1080p/29.97; 1080p/30; 1080p/50; 1080p/59.94; 1080p/60 1080PsF/23.98; 1080PsF/24; 1080PsF/25; 1080PsF/29.97; 1080PsF/30 1080i/50; 1080i/59.94; 1080i/60
2K video standards: 2Kp/23.98 DCI; 2Kp/24 DCI; 2Kp/25 DCI; 2Kp/29.97 DCI; 2Kp/30 DCI; 2Kp/50 DCI; 2Kp/59.94 DCI; 2Kp/60 DCI 2KPsF/23.98 DCI; 2KPsF/24 DCI; 2KPsF/25 DCI; 2KPsF/29.97 DCI; 2KPsF30 DCI
SDI compliance: SMPTE 259M, SMPTE 274M, SMPTE 296M, SMPTE 424M, SMPTE 425M A/B and SMPTE ST2108-1
Metadata support via SDI RP 188/SMPTE 12M-2 and Closed Captioning
SDI audio sampling rate: Standard television sampling rate of 48 kHz and 24 bits
SDI video sampling frequency: 4:2:2, 4:4:4
SDI colour accuracy: 8-, 10- and 12-bit RGB 4:4:4 up to 1080p/30 and 8- and 10-bit YUV 4:2:2 in all standards
SDI colour spaces: Rec. 601, Rec. 709, Rec. 2020
HDR support via SDI: HDR metadata packing, HLG and PQ transfer features
Multi-rate support SDI video connection is switchable between SD and HD
HDMI - SD video standards: 525i/59.94 NTSC, 625i/50 PAL
HDMI - HD video standards: 720p/50, 720p/59.94, 720p/60 1080p/23.98, 1080p/24, 1080p/25, 1080p/29.97, 1080p/30, 1080p/50, 1080p/59.94, 1080p/60 1080i/50, 1080i/59.94, 1080i/60
HDMI audio sampling frequency: Standard TV sampling rate of 48 kHz and 24 bit
HDMI video sampling frequency: 4:2:2 and 4:4:4
HDMI colour accuracy: 10- and 12-bit RGB 4:4:4 up to 1080p/30 and 8-bit YUV 4:4:4 and 12-bit YUV 4:2:2 in all standards
HDMI configuration: HDMI 2.0a supports Deep Colour and HDR
Automatically configures itself with the connected display
HDMI colour space: Rec. 601, Rec. 709, Rec. 2020
HDR support via HDMI: HDR metadata packing, HLG and PQ transfer features
Multirate support: SDI video connection is switchable between SD and HD
Copy protection: HDMI input cannot record from copy-protected HDMI sources
Hardware frame buffers: V210 (10-bit YUV), 2VUY (8-bit YUV), ARGB, BGRA (8-bit RGB), R210 (10-bit RGB), R12B, R12L (12-bit RGB)Dimensions: 92 x 45 x 25 mm
Included Accesories:
Thunderbolt 3 cable (1m)
Dimensions & Weight:
Height: 3.0cm
Width: 4.1cm
Depth: 13.2cm
Weight: 158 g
Downloads/Video:
View Video
